Mesh Wire

Mesh wire: commonly used galvanized wire drawing, galvanized wire hard wire.

Mesh wire tension requirements: at least greater than 550N.

Introduction to wire mesh: Because of the particularity of welding mesh, and taking into account some of the load-bearing connectivity of mesh welding, the common galvanized mesh wire on the market is generally divided into two kinds: galvanized to draw wire and galvanized hard wire. The tensile hardness is fully in line with the hardness requirements of the mesh for the wire. However, to take into account the load-bearing force of the mesh, the welding of the mesh must be firm. The solder joint must be firm and strong, and the phenomenon of open welding and virtual welding cannot occur. After a series of experiments and practice have proved that the hardness of the modified wire drawing is not only higher than that of ordinary galvanized wire, but also uniform wire diameter, solid welding, good load-bearing force, and product quality is higher than that of the same wire diameter welded mesh. Here is to introduce the characteristics of the change of wire drawing.

Galvanized wire drawing features: bright surface, higher hardness than ordinary galvanized wire, uniform wire diameter, easy to weld, strong adhesion of zinc layer. The solder joint is small and firm; It plays a role in improving product quality

Galvanized wire drawing coil diameter: 1.6mm-4.0mm inner diameter 45cm, 1.6mm below the inner diameter 20cm

Galvanized wire drawing specifications: wire diameter range 0.5mm-4.5mm, disc weight 0.5kg-500kg

Galvanized to wire drawing packaging: internal plastic external knitting, internal plastic external linen, internal plastic external plastic

Wire for welding mesh is generally not used ordinary electrogalvanized wire, because the electrogalvanized wire is too soft, and the welded mesh is not smooth.
